2.5-inch SFF SmartDrive Carrier Tray for HPE ProLiant Gen8 Gen9 — 651687-001 651699-001
Tech Specs
- Form factor: 2.5" SFF hot-swap SmartDrive (SC) carrier
- Drive interfaces: SAS / SATA (protocol support is determined by the server backplane)
- Includes: 4× drive-mounting screws
- Not for: 3.5" LFF cages
- Gen10 / newer note: Gen10 Plus and Gen11 use the BC tray family (e.g., P22892-001/-002). For Gen10 (non-Plus) NVMe, the common tray is 727695-001.
Key Features
☑️ SmartDrive latch with status-window design for clear drive state visibility
☑️ Precise fit in ProLiant SFF bays for reliable hot-swap operation
☑️ Broad cross-platform coverage across Gen8 and Gen9 SFF ecosystems
☑️ Ships with screws for ready-to-install convenience
✅ Confirmed Compatibility (SFF models / bays only)
✔️ DL360e Gen8 • DL360p Gen8 • DL320e Gen8
✔️ DL380e Gen8 • DL380p Gen8 • DL385p Gen8
✔️ DL560 Gen8 • DL580 Gen8
✔️ SL230s Gen8 • SL250s Gen8 (SFF drive cages)
✔️ ML310e Gen8 • ML350e Gen8 • ML350p Gen8
✔️ DL360 Gen9 • DL380 Gen9 • DL160 Gen9 • DL180 Gen9
✔️ DL560 Gen9 • DL580 Gen9
✔️ ML350 Gen9 • ML150 Gen9 • ML110 Gen9 (with SFF cage option)
If your chassis is LFF/3.5", use the 3.5" tray (e.g., 651314-001) or a 2.5"→3.5" adapter as appropriate.
Interchangeable / Related Part Numbers
- Interchangeable trays (SFF SmartDrive): 651687-001, 651699-001, 651699-003
- Related (different families or form factors, for reference): 727695-001 (Gen10 non-Plus NVMe SFF), 651314-001 (3.5" LFF SmartDrive tray)
Related Backplane Kits (reference only — not included)
Use these SFF cage/backplane kits with the tray above (examples from common Gen9 platforms):
- DL380 Gen9: 719067-B21 (8-SFF Bay 1 cage/backplane), 768857-B21 (additional 8-SFF Bay 2 cage/backplane)
- DL360 Gen9: 768857-B21 (8-SFF Bay 2 cage/backplane)
- ML350 Gen9: 778157-B21 (8-SFF cage/backplane kit)
- DL360 Gen9 NVMe enablement (2× SFF NVMe): 764628-B21 (tray fits SFF bay; NVMe support depends on this enablement/backplane)
What’s Included
- 1× 2.5" SFF SmartDrive tray (651687-001 or 651699-001)
- 4× drive-mounting screws
