980W Power Supply for Mac Pro A1186 2007 2008

High-power 980W internal power supply assembly for the classic aluminum Mac Pro tower (A1186). Designed for original 4-core and 8-core configurations with multiple hard drives, PCIe graphics cards, and high CPU loads. This unit is a direct replacement for the 980W PSU used in 2007–2008 Mac Pro towers and supports the full factory power envelope.

This 980W power supply is built for the A1186 Mac Pro chassis and delivers stable +12V rails for dual CPUs, high-end GPUs, and multiple storage devices. It uses the original Mac Pro style 10-pin and 12-pin harness connections and matches the physical form factor, mounting points, and airflow path of the factory unit.

Ideal as a replacement for a failed PSU or for restoring a classic Mac Pro tower to reliable service.

Technical Specifications

• Max Power: 980W
• AC Input: 100–240V~, 50–60Hz, 12–5A
• Form Factor: Internal PSU module for A1186 tower enclosure
• Dimensions: 153 mm x 97 mm x 174 mm


• DC Output Rails:
• +12V1: 13.6A
• +12V2: 13.6A
• +12V3: 16.5A
• +12V4: 12.8A
• +12V5: 18A
• +12V6: 11A
• +5VSB: 5A


• Connectors / Harness:
• (3) x 10-Pin power connectors (J1, J2, J4 – approx. 12" leads)
• (1) x 12-Pin power connector (J3 – approx. 12" lead)


• Mounting: Direct drop-in replacement for original 980W PSU with matching screw locations and rear AC inlet position

Interchangeable / Replacement Part Numbers

This unit is a functional equivalent / direct replacement for the following 980W Mac Pro A1186 power supplies (same capacity, form factor, and harness layout):

API6PC01, 614-0400, DPS-980BB A, 614-0409, 614-0407, DPS-980AB A, 614-0383

✅ Confirmed Compatibility

Please note that the following list is not exhaustive. Compatibility depends on your system's specific configuration. It's essential to verify compatibility with your system or enclosure manufacturer prior to installation.

✔ Mac Pro Towers (A1186 Aluminum Enclosure):
Mac Pro (Mid 2007) – A1186 tower (quad-core / 8-core configurations),
Mac Pro (Early 2008) – A1186 tower (quad-core / 8-core configurations)

If your existing power supply label shows one of the interchangeable part numbers listed above and is installed in an A1186 aluminum Mac Pro tower (2007–2008 generation), this unit is intended as a direct replacement.

☑️ Key Features

☑️ 980W high-capacity PSU designed specifically for the A1186 Mac Pro tower
☑️ Correct 10-pin and 12-pin harnesses for motherboard, backplane, and auxiliary power
☑️ Supports dual-CPU, multi-GPU, and multiple hard drive / optical bay configurations
☑️ Auto-sensing 100–240V input for worldwide use
☑️ Direct physical fit – no modifications required to chassis or wiring

⚙️ Fit Notes

• Designed only for the classic aluminum tower with model number A1186 (side panel label); not suitable for later A1289 Mac Pro towers (2010–2012) or any cylindrical / “trash can” Mac Pro.
• Before replacing the PSU:

• Shut down the machine and disconnect the AC power cable.
• Allow several minutes for internal capacitors to discharge.
• Remove all side and internal access panels as per OEM service guides.

• Reuse the original mounting screws and follow the original cable routing to avoid pinching cables or obstructing airflow.
