CZ-K1P - RGB Digital Fiberoptic Sensor Amplifier PNP 12-24VDC 300 us 1 ms 2 m Cable

CZ-K1P - RGB Digital Fiberoptic Sensor Amplifier PNP 12-24VDC 300 us 1 ms 2 m Cable

Description

Keyence CZ series color sensor amplifier with PNP output and built-in 2 m lead. Uses RGB LED illumination and digital processing for reliable color match or mismatch detection. Front-panel display with calibration and tolerance settings makes setup fast on packaging, labeling, and assembly lines.

Technical Specifications

• Model: CZ-K1P
• Output type: PNP open-collector, 40 VDC max 100 mA max, residual ≤ 1.0 V
• Supply voltage: 12–24 VDC ±10 percent, ripple ≤ 10 percent p-p
• Light source: Red Green Blue LED
• Response time: 300 us / 1 ms switch-selectable
• Display and indicators: LCD matching/received-light display plus LEDs for output calibration and external sync
• Calibration modes: 1-point or 2-point selectable
• Differentiation modes: C mode / C+I mode / I mode selectable
• Timer: OFF-delay 40 ms or OFF
• External inputs: Sync input 500 us max response, external calibration and 8-bank registered color selection 20 ms min
• Protection: Reverse-polarity power protection overcurrent protection surge absorber on output
• Current consumption: ≤ 75 mA
• Case material: Polycarbonate
• Ambient rating: −10 to +55 °C 35–85 percent RH no condensation
• Vibration / shock: 10–55 Hz 1.5 mm double amplitude 2 h per axis / 500 m s² 3 times per axis
• Cable length: 2 m integrated lead
• Weight: ≈ 0.25 lb including cable

Interchangeable / Replacement Part Numbers

• Exact item on this page: CZ-K1P
  (Heads such as CZ-Hxx are separate part numbers and must be selected to match your distance and spot requirements.)

✅ Confirmed Compatibility

Compatibility depends on fiber head selection and I O polarity. Match by amplifier code and choose a CZ series fiber head appropriate for your working distance and target finish.

✔ Applications: Color mark presence verification lot code label color confirmation cap color sorting film and carton color checks on high-speed lines
✔ Control I O: PLC or controller inputs expecting PNP transistor sensors at 12–24 VDC
✔ Mounting: DIN-rail or bracket mounting in compact enclosures

☑️ Key Features

• RGB LED illumination with digital color evaluation for stable match or mismatch results
• Fast 300 us setting for high throughput or 1 ms for added stability
• 1-point or 2-point calibration with numeric tolerance setting on the display
• Eight registered color banks selectable via external input for quick changeovers
• Robust protections and clear status indicators to simplify commissioning and diagnostics
