HP 773836-1B1 - BO03XL 3-Cell Battery for HP Chromebook 14-X 14 G3 Stream 14-Z 14-P SlateBook 14-P Series

BO03XL – 3-Cell 11.4V 32Wh Li-ion Battery for HP Chromebook 14-x / 14 G3 / Stream 14-z / SlateBook 14-p Series

High-quality internal lithium-ion battery designed for select Chromebook, Stream, and SlateBook 14-inch series laptops.
This BO03XL pack delivers reliable 11.4V output and 32Wh capacity, ensuring consistent runtime and power stability in lightweight HP systems.

Technical Specifications

• Model: BO03XL
• HP Spare Part Number (SPS): 761230-005, 761230-851, 761231-005, 761231-851 (family)
• Battery Type: Li-ion
• Voltage: 11.4V
• Capacity: 32Wh / 2960mAh
• Cells: 3-Cell
• Energy Class: 3C 32Whr 2.96Ah
• Form Factor: Internal battery pack (with connector cable)
• Color: Black
• Includes: Connector harness pre-attached

Interchangeable / Replacement Part Numbers

BO03XL, BO03032XL, BO03032XL-PL, BO03032XL-PR,
HSTNN-UB6R, HSTNN-LB6S, HSTNN-IB6S, HSTNN-UB6S,
761230-005, 761230-851, 761231-005, 761231-851,
TPN-Q155, 754744-001, 754745-001, 756743-005

(All above belong to the same 11.4V 32Wh BO03XL pack family. Avoid mixing with 7.5V or 48Wh variants.)

✅ Confirmed Compatibility

Please note that the following list is not exhaustive. Compatibility depends on your system’s exact model and configuration. Verify by part number on your original battery before purchase.

✔️ Chromebook Series:
Chromebook 14-x000, 14-x000na, 14-x000no, 14-x001nd, 14-x001nf, 14-x002no, 14-x003nf, 14-x004na, 14-x005tu, 14-x010nr, 14-x010wm, 14-x013dx, 14-x020nr, 14-x030nr, 14-x040nr, 14-x050nr, 14-x055sa, 14-x094nf, 14-x097nf
Chromebook 14-2000, 14-q000, 14 G3 Series

✔️ Stream Series:
Stream 14-z000, 14-z001, 14-z005, 14-z010, 14-z020, 14-z040wm, 14-z050sa, 14-z051sa, 14-z080no, 14-z090ng

✔️ SlateBook Series:
SlateBook 14-p000, 14-p010nr, 14-p080no, 14-p091nr

✔️ Other Compatible SKUs:
K3X08EA, K4K11UT, K4K83UA, K5F83AA, K7V51PA, L8C14ES, N3C94UC, and similar Chromebook 14-x / Stream 14-z configuration codes.

☑️ Key Features

☑️ 11.4V, 32Wh energy capacity for lightweight HP Chromebook and Stream notebooks
☑️ Genuine-spec 3-cell Li-ion chemistry with integrated protection board
☑️ Includes connector cable for quick internal replacement
☑️ Verified compatibility with Chromebook 14 G3 / 14-x, Stream 14-z, and SlateBook 14-p models
☑️ Meets HP OEM voltage and form-fit standards for safe operation

 Fit Notes

• This is an internal battery pack; disassembly of the lower case is required for installation.
• Ensure your original battery is labeled BO03XL or one of the equivalent PNs listed above.
