KDE1206PHV2 - 60x60x15mm 6015 DC12V 1.0W 2-Wire 2-Pin Connector DC Brushless Cooling Fan
Description
Compact 60mm x 15mm DC brushless cooling fan designed for control modules, inverter bays, and electronics enclosures where reliable spot cooling is required. Operates at 12V DC with a simple 2-wire lead and connector.
Technical Specifications
- Dimensions: 60 x 60 x 15 mm (6015)
- Rated Voltage: DC 12V
- Rated Power: 1.0W
- Interface: 2-wire lead with 2-pin connector (+V / GND)
- Fan Type: DC brushless axial
- Mounting: Standard 60mm square pattern
- Airflow/Rotation Indicators: Arrows molded on housing
- Features: Auto-restart and polarity protection typical for this class
Interchangeable / Replacement Part Numbers
✅ Confirmed Compatibility
Please note that the following list is not exhaustive. Compatibility depends on your system's specific configuration. It's essential to verify compatibility with your system or enclosure manufacturer prior to installation.
✔ Inverter and VFD cooling bays
✔ PLC and automation control panels
✔ Embedded electronics and networking gear
✔ Compact power supplies and equipment housings
☑️ Key Features
- ☑️ 60x60x15mm 6015 footprint for space-constrained installs
- ☑️ 12V DC operation with low 1.0W power draw
- ☑️ Simple 2-wire hookup for quick replacement
- ☑️ Brushless design for stable, continuous duty
- ☑️ Standard 60mm mounting for broad mechanical fit
⚙️ Fit Notes
- Verify your device requires a 60x60x15mm 12V DC 2-wire fan and that the connector type and pinout match your harness.
- Typical wiring convention: Red = +12V, Black = Ground (confirm on your controller).
- Align airflow and rotation with the molded arrows on the frame; keep intake/exhaust paths unobstructed.
- This 2-wire model does not provide tach feedback or PWM control—it runs at native speed when powered.
