5915PC-12T-B30 - 172x150x38mm 115VAC 1-Phase 50/60Hz 2-Terminal Ball Bearing AC Axial Cooling Fan

This 172mm x 150mm x 38mm AC axial cooling fan is designed for industrial control cabinets, drive systems, enclosures, and other equipment that require dependable continuous-duty airflow. It uses a ball bearing design, 115VAC input, and 2-terminal connection style, making it a practical replacement for control panel, CNC, robotics, telecom, rack, and power equipment cooling applications where this exact frame size and electrical configuration are required.

Technical Specifications

• Part Number: 5915PC-12T-B30
• Fan Type: AC axial cooling fan
• Frame Size: 172mm x 150mm x 38mm
• Voltage: 115VAC
• Phase: 1-Phase
• Frequency: 50/60Hz
• Power Consumption:
  • Approx. 35W at 50Hz
  • Approx. 32W at 60Hz
• Bearing Type: Ball bearing
• Termination: 2 quick-connect terminals
• Airflow Direction: From open side toward strut / label side
• Life Expectancy: L10 100,000 hours at 25°C
• Performance at 50Hz:
  • Speed: 2700 RPM
  • Airflow: 176.5 CFM
  • Static Pressure: 0.629 in H2O
  • Noise Level: Approx. 52 dBA
• Performance at 60Hz:
  • Speed: 3200 RPM
  • Airflow: 212 CFM
  • Static Pressure: 0.865 in H2O
  • Noise Level: Approx. 56 dBA

Interchangeable / Replacement Part Numbers

5915PC-12T-B30, 5915PC-12T-B30-A00, 5915PC-12T-B30-S00, 5915PC-12T-B30-AM0

✅ Confirmed Compatibility

Please note that the following list is not exhaustive. Compatibility depends on your system's specific configuration. It's essential to verify compatibility with your system or enclosure manufacturer prior to installation.

✔️ Industrial Control Cabinets: Standard 172x150x38mm fan cutouts using a 115VAC terminal-style axial cooling fan
✔️ VFD and Drive Enclosures: Variable frequency drive cabinets, inverter enclosures, and motor control systems requiring this size and voltage class
✔️ CNC and Robotics Enclosures: CNC control cabinets, robotics systems, and automation panels using a 172x150x38mm AC cooling fan with 2-terminal connection
✔️ Telecom and Rack Equipment: Industrial rack, telecom, and electronics enclosures that use a 115VAC axial fan in this frame size
✔️ Retrofit and Replacement Applications: Existing equipment already using a 172x150x38mm 115VAC ball bearing fan with quick-connect terminal lugs

☑️ Key Features

☑️ High-airflow axial cooling performance for dense cabinets and electronic enclosures
☑️ 115VAC 50/60Hz operation for industrial and equipment cooling applications
☑️ Ball bearing design for long service life and dependable continuous-duty operation
☑️ 2-terminal quick-connect style for fast field replacement
☑️ Strong static pressure performance for restrictive cabinet and panel airflow paths
☑️ Suitable for control cabinets, CNC equipment, robotics, drives, and enclosure cooling

⚙️ Fit Notes

• Please match the full part number, frame size, voltage, frequency, terminal style, and airflow direction before ordering.
• Confirm your cabinet or equipment has clearance for the full 38mm depth.
• This is a 115VAC fan and is not interchangeable with low-voltage DC fans unless all specifications match exactly.
• Airflow exits toward the strut / label side, so installation orientation is important.
• Verify your application uses 2 quick-connect terminals and not a plug-style or lead-wire connection.
