130W USB-C AC Adapter Charger for XPS 15 9500 9510 9520 XPS 17 9700 9710 9720 Precision 5550 5560 Latitude 5520 5531

Tech Specs

• Output: 20V 6.5A up to 130W (USB-C PD)
• Additional PDOs: 15V 3A · 9V 3A · 5V 3A
• Input: 100–240V 50/60Hz
• Connector: USB-C (Power Delivery)
• Cable: AC power cord included with most kits
• Form factors: Standard brick and slim GaN versions (both 130W)

☑️ Key Features

☑️ Full 130W over USB-C on supported systems
☑️ Backward-compatible with 100W 90W 65W USB-C PD (auto-negotiates down)
☑️ Travel-friendly slim GaN option available
☑️ Global voltage for home office or travel

✅ Confirmed Compatibility

(Models that support 130W over USB-C; not limited to)

XPS
✔️ XPS 15 9500 9510 9520 9575 2-in-1
✔️ XPS 16 9640
✔️ XPS 17 9700 9710 9720

Precision Mobile Workstations
✔️ Precision 5530 2-in-1
✔️ Precision 5470 5480 5490
✔️ Precision 5550 5560 5570
✔️ Precision 5750 5760 5770
✔️ Precision 3470 3480 3490
✔️ Precision 3541 3551 3560 3561 3570 3571 3580 3581 3590 3591

Latitude (performance lines with 130W USB-C)
✔️ Latitude 5401 5411 5421 5431
✔️ Latitude 5501 5511 5520 5521 5531

Inspiron / Vostro
✔️ Inspiron 16 7620 7630 7640
✔️ Vostro 16 7000 7620

Alienware compact gaming
✔️ x14 R1 x14 R2
✔️ M17 R3 (USB-C input supported; may limit under extreme load)

Interchangeable / Equivalent Part Numbers

Device DP/N (label codes)
7MP1P · K00F5 · CT1P3 · M0H25 · CW1FP · MDH25 · T4V18 · V7K50 · VW0G0

Adapter “Model” codes (printed on label)
DA130PM170 · HA130PM170 · DA130PM200 · LA130PM200 · LA130PM170

Retail kit numbers
450-AHOM · 450-AHRK · 492-BDPB (130W slim GaN kit) · GNH73 (GaN mfr code)

All items above are the same 130W USB-C class and are interchangeable within this listing.

Replaces Lower-Watt USB-C Adapters

Use this where a lower-watt USB-C PD brick was supplied; the system will negotiate to its design limit.

100W class

• DP/N: 450-BBNN · 492-BDNJ · 492-BDKM · FJHVF · 5YXW8
• Model: DA100PM170 · HA100PM220 · LA100PM220 · DA100PM230 · LA100PM230

90W class

• DP/N: 0MDD7C · R2M8K · Y2XGV · TDK33 · 492-BCBK
• Model: LA90PM170 · DA90PM170 · HA90PM170

65W class

• DP/N: 492-BDQM · 492-BDQS · 02YK0F · 0M1WCF · 0JYJNW
• Model: LA65NM170 · HA65NM170 · DA65NM170 · LA65NM190 · HA65NM190

What’s Included

• 130W USB-C AC adapter
• AC power cord (kit dependent)

Fit Notes

• USB-C connector only — not 4.5 mm or 7.4 mm barrel tip.
• For full 130W behavior, use with models listed in Confirmed Compatibility.
• Systems designed for ≤100W via USB-C will charge at their designed limit.

Quick Label Check

• Power rating: Look for 130W on the output line (e.g., 20V 6.5A).
• Port marking: USB-C / PD logo near the DC symbol.
• Model (printed “Model”): DA130PM170 · HA130PM170 · DA130PM200 · LA130PM200 · LA130PM170
• DP/N (label code): 7MP1P · K00F5 · CT1P3 · M0H25 · CW1FP · MDH25 · T4V18 · V7K50 · VW0G0
• Retail kit (box label, if present): 450-AHOM · 450-AHRK · 492-BDPB (slim GaN) · GNH73

Fast rule of thumb: if the model string contains “130PM” it’s a 130W USB-C unit; strings like “100PM / 90PM / 65PM” indicate lower-watt versions.
