DFS5K12114262H - GPU Cooling Fan for Asus TUF Gaming FX505 FX505GE FX505GM FX505DT FX705 FX86FE FX86FM FX86SM Series Gaming Laptop

GPU Cooling Fan for Asus TUF Gaming FX505 FX505GE FX505GM FX505DT FX705 FX86FE FX86FM FX86SM Series

Technical Specifications

Part Number: DFS5K12114262H
Type: GPU Cooling Fan
Voltage: DC 5V
Current: 0.5A
Connector: 4-Pin
Cable: 4-Wire PWM design (power, ground, tach, control)
Bearing Type: Fluid Dynamic Bearing (FDB)
Motor Type: Brushless DC Motor
Material: Metal frame with high-efficiency plastic impeller
Dimensions: Approx. 75 × 75 × 10 mm (ultra-slim profile)

Interchangeable / Replacement Part Numbers

DFS5K12114262H, 1323-01AY0A2, DQ5D577K002, 13NR00S0M10011

✅ Compatible Models

✔️ Asus TUF Gaming FX505 Series – FX505GE, FX505GM, FX505DT, FX505DU, FX505DY, FX505GT, FX505DD
✔️ Asus TUF Gaming FX705 Series – FX705GE, FX705GM, FX705DT, FX705DY
✔️ Asus TUF Gaming FX86 Series – FX86FE, FX86FM, FX86SM

(Compatibility not limited to the above models – verify by fan part number and connector style.)

 Cross References

Works together with the CPU Cooling Fan (sold separately):
DFS5K12304363H – CPU Cooling Fan for Asus TUF Gaming FX505DU FX505DY FX505GT FX505DD Series

For optimal thermal contact during reassembly, use:
Shin-Etsu G751 Microsi High-Performance Thermal Grease / Thermal Paste

☑️ Key Features

☑️ 4-Pin PWM fan for dynamic GPU temperature control
☑️ Quiet operation with high airflow and low vibration
☑️ Precision-balanced impeller for stability under load
☑️ Direct-fit replacement for factory-installed GPU fan
☑️ Ideal for restoring performance and preventing GPU overheating

⚙ Fit Notes

• Designed for the GPU side of dual-fan cooling assemblies in Asus TUF Gaming laptops.
• Install alongside matching CPU fan (DFS5K12304363H) for best results.
• Always reapply thermal paste to GPU die before reinstalling the heatsink.
• Ensure fan connector matches the original (4-pin, PWM type).
