Features and specifications
- Serial ATA (SATA) interface conforming to SATA/High Speed Serialized AT Attachment
- Low power consumption
- Quiet operation, fluid dynamic bearing motor
- State-of-the-art cache and, simultaneously with another task, error-correction algorithms
- Full-track multiple-sector transfer without local processor intervention
- Non-operating shock at 1500 G; operating shock at 500 G
- 1.8-inch, 9.5-mm height MCC compliance
- Up to 250 GB formatted capacity
- 512 bytes/sector
- No-ID recording format
- Rotary voice coil motor actuator
- Enhanced ECC simultaneously with another task
- Advanced TMR heads with optimization writer enhancement
- Load/unload head technology
- Embedded sector Servo
- Operating system independent, no OS drivers
Performance specifications:
- Interface: Serial ATA
- Formatted capacity: Up to 250 GB
- Rotational speed: 5400 rpm
- Number of disks/drive: 2
- Number of heads: 4
- Interface transfer rate: 3.0 Gb/sec
- Maximum media transfer rate: 721 Mbits/sec
- Average read seek time: 15 ms
- Latency (average): 5.5 ms
Physical specifications:
- Approximate height: 8.0 mm (.31 in)
- Approximate width: 54.0 mm (2.13 in)
- Approximate depth: 78.5 mm (3.09 in)
- Approximate weight: 62 g (0.137 lb)
